Glass Testing Machine

The BMT-E Series Servo Electromechanical Glass Testing Device is a highly efficient and precise testing system that is designed with a rigid frame in wall type construction. It is equipped with a highly precise and efficient AC servo motor and gapless electromechanical drive system, and a BESMAK electronic control unit. The system is electromechanical motor driven and software controlled via computer, making it easy to use and functional.

This testing device can perform a range of testing applications, including tensile, compression, and bending tests with high precision and stability. It can be used in a variety of industries, including automotive, defense and aerospace, medical, iron and steel, building materials, and more. The system is designed to meet the basic universal physical testing needs of many sectors and offers extensive testing flexibility for users to meet changing requirements.

The BMT-E Series Servo Electromechanical Glass Testing Device is designed to meet the requirements of all national and international standards, including ISO, ASTM, BS, DIN, EN, and AFNOR. It also features a comfortable working height and ergonomic control structure that increases user productivity and comfort. The electronic control unit has more than one emergency stop I/O configuration and is suitable for connecting many emergency stop buttons, ensuring that the operator can intervene quickly in case of emergencies.

This testing device offers thousands of accessories that meet the testing requirements of any application or industry, including biomedical, automotive, electronics, plastic, glass, metal, composite, elastomer, aerospace, textile, and many more. It also features real-time data display, a multi-functional smart keypad, and sample protection infrastructure and smart control console (optional) for enhanced use and productivity.

In summary, the BMT-E Series Servo Electromechanical Glass Testing Device is a highly efficient, precise, and versatile testing system that can be used in a variety of industries and applications. Its advanced features and flexible design make it easy to use and suitable for meeting changing testing requirements.

Applications:

• TS EN 1279-4 - Filling machine control glazing (linear incremental)
• TS EN 1279-6 - Glass pull (constant load)
• TS EN 1279-6; Lath pulling
• EN 1288 - can perform 4-point compression-bending test with the support of the relevant appartus

Includes:

• Rigid 20 kN capacity 2 column test frame
• SEMATRON electronic control unit
• Universal testing software
• A 3-point and 4-point bending test accessory
• A C type tensile jaw with a capacity of 2 kN
• Pull lathe jaw
• Glass tensile jaw

BESMAK 20 kN Capacity Servo Electromechanical, Universal Testing Machine, can work tensile, compression, bending etc tests (may need optional fixtures) and can work on both load control mode and displacement / deformation control mode.Two column rigid construction.

Load measurement and control, with a load cell of class 0.5, 1 kHz data accusation Close-loop electronic controller, Crosshead moving speed (mm/min): 0.001-500.

The electronic control unit of system is with 1000 samples per second data acquisition speed. Accurate synchronization between frame and sensors will be done/controlled by advanced PID close loop control configuration. Electronic control unit has total 5 channels (2 internal, 2 external and 1 RS232/485). Due to these channels electronic control unit can control 7 no. sensors at same time.

Electronic control unit is feasible to attach and control video extensometer, laser extensometer, LVDT, automatic extensometer, strain gauge, load cell, SSI and TTL type sensors (optional). Special Eeprom sensor plugs can store calibration and sensor data inside it. Due to this feature control unit can read sensor and calibration data even if user change it with new unit.

Software: User can read and control each attached sensor with control unit, for example; 2nd load cell, LVDTs and extensometers. can perform load and displacement controlled test, position measurement and control with position encoder of 1 micron resolution, handheld unit to move machine up and down without use of computer to fix sample into the machine easily accurately and safely, Load channel with a resolution of ±180,000 steps, adjustable load control in between 0.01kN/s - 5kN/s, adjustable displacement control in between 0.001 - 500 mm/min, testing software, user defined result parameters (connected to load and position), result can be transferred to Excel format(Raw Values).
