BESMAK Jolting Apparatus for Cement Mortar Prisms according to EN 196-1 and EN ISO 679

JOLTING APPARATUS FOR CEMENT MORTAR PRISMS – BCE-309

The Jolting Apparatus for Cement Mortar Prisms is designed to compact cement mortar specimens measuring 40×40×160 mm in moulds for compressive and flexural strength testing. Manufactured in accordance with EN 196-1, EN ISO 679, and BS 3892, the equipment provides consistent and repeatable specimen preparation for cement quality control laboratories, universities, research institutes, and construction material testing facilities.
Its automatic operating system delivers 60 jolts per minute, ensuring uniform compaction while minimizing operator influence. The built-in LCD counter accurately records the number of blows and automatically stops the machine once the preset count is completed.

Category:

Features of the Jolting Apparatus for Cement Mortar Prisms

  • Designed for compacting 40 × 40 × 160 mm cement mortar prism specimens
  • Complies with EN 196-1
  • Manufactured in accordance with EN ISO 679
  • Suitable for BS 3892
  • Automatic compaction cycle
  • Operates at 60 jolts per minute
  • Built-in LCD blow counter
  • Automatic stop after the preset number of jolts
  • Heavy-duty steel construction
  • Easy operation and low maintenance

Technical Specifications

Specification Value
Power Supply 220 V, 50 Hz
Compaction Speed 60 jolts per minute
Dimensions 395 × 1050 × 275 mm
Weight Approx. 85 kg

Applications

The BESMAK Jolting Apparatus for Cement Mortar Prisms is widely used in:

  • Cement testing laboratories
  • Construction materials testing laboratories
  • Quality control laboratories
  • Universities
  • Research institutes
  • Ready-mix concrete laboratories
  • Cement manufacturing plants
  • Independent testing laboratories

Standards

The BESMAK Jolting Apparatus for Cement Mortar Prisms complies with the following international standards:

  • EN 196-1
  • EN ISO 679
  • BS 3892

Available Models

Product Code Product Name
BCE-309 Jolting Apparatus
BCE-309/1 Sound Proof Cabin for Jolting Table
BCE-309/2 Jolting Table Mold Holder

Why Choose BESMAK Jolting Apparatus for Cement Mortar Prisms?

The BESMAK Jolting Apparatus for Cement Mortar Prisms provides accurate, reliable, and repeatable compaction of cement mortar specimens for strength testing. Its automatic compaction cycle, integrated LCD counter, and robust steel construction ensure consistent specimen preparation while reducing operator influence.

Designed to comply with internationally recognized EN and ISO standards, it is an ideal solution for laboratories performing routine cement strength testing.



Frequently Asked Questions (FAQ)

What is a Jolting Apparatus for Cement Mortar Prisms used for?

It is used to compact fresh cement mortar into 40 × 40 × 160 mm prism molds prior to flexural and compressive strength testing.

Which standards does this machine comply with?

The machine complies with the following standards:

  • EN 196-1
  • EN ISO 679
  • BS 3892

How many jolts does the machine perform?

The Jolting Apparatus operates at 60 jolts per minute, as specified by the applicable testing standards.

Does the machine stop automatically?

Yes. The built-in LCD counter records the number of jolts and automatically stops the machine once the preset compaction cycle is completed.

Which laboratories use this equipment?

The equipment is widely used in:

  • Cement manufacturing plants
  • Construction materials laboratories
  • Universities
  • Research institutes
  • Quality control laboratories
  • Independent testing laboratories
